CM8822 LANDTEK Coating Thickness Gauge Price in Pakistan
Buy CM8822 LANDTEK Coating Thickness Gauge at best price in Pakistan 2026.
The CM8822 LANDTEK Coating Thickness Gauge is a high-precision digital instrument designed to measure the thickness of coatings such as paint, plating, enamel, and protective layers on metal surfaces. It features dual measurement technology (F & NF probes), allowing accurate testing on both magnetic and non-magnetic substrates.
This device uses magnetic induction (F) for measuring non-magnetic coatings on steel/iron and eddy current (NF) for measuring non-conductive coatings on aluminum and other non-magnetic metals.
With a wide measurement range up to 0–1000µm, high accuracy, and dual measurement modes (single & continuous), the CM8822 is ideal for professionals working in automotive, manufacturing, electroplating, and industrial quality control.
Available for delivery in Karachi, Lahore, Islamabad, and all over Pakistan.
Key Features
Dual measurement technology (Magnetic Induction + Eddy Current)
F & NF probes for multi-surface testing
Measurement range up to 1000µm
High accuracy with reliable repeatability
Single and continuous measurement modes
Automatic substrate recognition
Auto calibration memory function
Metric and imperial unit selection
Low battery indication and auto power-off
Compact, portable, and industrial-grade design
Technical Specifications
Electrical Measurement Ranges
Measurement Range: 0 – 1000µm (0 – 40 mil)
Resolution: 0.1µm / 1µm
Accuracy: ±1–3% or ±2.5µm
Measurement Principle: Magnetic Induction (F) + Eddy Current (NF)
Minimum Measuring Area: 6mm
Minimum Substrate Thickness: 0.3mm
General Specifications
Display: 4-digit LCD
Measurement Modes: Single / Continuous
Units: µm / mil selectable
Power Supply: 4 × AA batteries
Operating Temperature: 0°C – 50°C
Humidity: <80% RH
Dimensions: Approx. 161 × 69 × 32 mm
Weight: Approx. 250g
Applications
Automotive paint thickness inspection
Industrial coating and plating measurement
Powder coating and galvanizing inspection
Metal surface protection analysis
Manufacturing quality control
Furniture and surface finishing inspection
Laboratory and industrial testing
Package Includes
LANDTEK CM8822 Coating Thickness Gauge
F-type probe (magnetic)
NF-type probe (non-magnetic)
Calibration foils set
Iron and aluminum calibration base
Carrying case
User manual
