Features
* In accordance with ISO 2954, used for periodic measurements, to detect out-of-balance, misalignment and other mechanical faults in rotating machines.
* Specially designed for easy on site vibration measurement of all rotating machinery for quality control,commissioning, and predictive maintenance purposes.
* Individual high quality ccelerometer for accurate and repeatable measurements.
* Optional headphones for use as electronic stethoscope.
* Bearing condition monitoring function.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
Vibration Standard
ISO/IS2373 Motor Quality Standard According As Vibration Velocity
|
Quality Rank
| Rev(rpm)
| H:high of shaft(mm)
Maximum vibration velocity rms(mm/s)
|
80<H<132
| 132<H<225
| 225<H<400
|
Normal
| 600~3600
| 1.8
| 2.8
| 4.5
|
Good(R)
| 600~1800
| 0.71
| 1.12
| 1.8
|
1800~3600
| 1.12
| 1.8
| 2.8
|
Excellent(S)
| 600~1800
| 0.45
| 0.71
| 1.12
|
1800~3600
| 0.71
| 1.12
| 1.8
|
Specifications
| Sensor | Piezoelectric Transducer |
| Measuring Range | Acceleration | -------- |
| Velocity | 0.01~199.9mm/s True RMS |
| Displacement | -------- |
| Frequency Range | Acceleration | -------- |
| Velocity | 10Hz~1kHz |
| Displacement | -------- |
| Accuracy | 5% of Reading+2 digits |
| Operating Conditions | Temperature | 0~50ºC |
| Humidity | <90%RH |
| Power Supply | 4x1.5V AA(UM-3)Battery |
| Dimensions | 160x68x32mm |
| Weight | 181g(Not Including Batteries) |
| Standard Accessories | Main Unit |
| Piezoelectric Transducer |
| Powerful Rare Earth Magnet |
| Probe(Cone)&Probe(Spherical) |
| Carrying Case(B04) |
| Manual Book |
| Optional Accessories | Headset |
| RS-232C Data Cable with Software |
| Bluetooth Data Adapter with Software |
