TM8812 LANDTEK Ultrasonic Thickness Meter Price in Pakistan

Buy TM8812 LANDTEK Ultrasonic Thickness Meter at best price in Pakistan 2026.

The TM8812 LANDTEK Ultrasonic Thickness Meter is a high-precision digital instrument designed to measure the thickness of metallic and non-metallic materials using advanced ultrasonic technology. It is widely used in industries such as oil & gas, shipbuilding, manufacturing, and power plants for detecting corrosion, erosion, and material wear.

This device works by transmitting ultrasonic waves through the material and measuring the time taken for the echo to return, providing accurate thickness readings without damaging the surface. It is suitable for materials like steel, aluminum, brass, glass, ceramics, and plastics with parallel surfaces.

With a measurement range up to 1.2mm to 200mm+, high accuracy, and portable design, the TM8812 is ideal for engineers, technicians, and maintenance professionals across Pakistan. It also features adjustable sound velocity, built-in calibration block, and data output options for professional use.

Available for delivery in Karachi, Lahore, Islamabad, and all over Pakistan.

Key Features

High-precision ultrasonic thickness measurement
Non-destructive testing (NDT) method
Measures both metallic and non-metallic materials
Wide measurement range up to 200mm+
Adjustable sound velocity for different materials
Built-in calibration test block
LCD display with mm/inch selection
RS-232 / USB data output support
Portable, lightweight, and easy to use
Low battery indication and auto power-off

Technical Specifications

Electrical Measurement Ranges

Measurement Range: 1.2mm – 200mm (steel)
Resolution: 0.1mm
Accuracy: ±(0.5%H + 0.1) mm
Sound Velocity Range: 1000 – 9000 m/s
Probe Frequency: 5 MHz

General Specifications

Display: 4-digit LCD (10mm height)
Measurement Units: mm / inch selectable
Power Supply: 4 × AA batteries
Operating Temperature: 0°C – 50°C
Humidity: <85% RH
Dimensions: Approx. 120 × 62 × 30 mm
Weight: Approx. 250g

Applications

Pipe thickness and corrosion testing
Oil & gas industry inspections
Boilers and pressure vessel testing
Shipbuilding and marine inspection
Automotive and manufacturing industries
Metal sheet and plate thickness measurement
Quality control and maintenance operations

Package Includes

LANDTEK TM8812 Ultrasonic Thickness Meter
Ultrasonic probe (sensor)
Coupling gel
Carrying case
User manual
