Landtek BTT2880S Sonic Belt Tension Tester In Pakistan

Buy Now Landtek BTT2880S Sonic Belt Tension Tester At Best Price In Pakistan 2026.

The Landtek BTT2880S Sonic Belt Tension Tester is a professional belt tension measurement tool that uses sonic vibration frequency to determine the tension of belts without physical contact. It detects the natural vibration of a belt when tapped or moving and converts this frequency into a precise tension value using built-in calculations. This makes it ideal for maintenance in automotive, industrial, conveyor, HVAC, and mechanical belt-driven systems.

Key Features

• Measures belt vibration frequency from 10 Hz to 680 Hz for accurate tension calculation.
• Detachable directional probe for easy access in tight spaces.
• Stores up to 20 belt parameter sets in memory.
• Automatic power-off to save battery.
• Easy-to-read LCD display shows frequency and tension values.
• Lightweight and portable design for field and workshop use.

Technical Specifications

Frequency Range

Maximum Belt Parameters

• Belt length (free span): up to 999.9 mm
• Belt width: up to 999.9 mm
• Belt mass: up to 999.9 g/m

Accuracy & Precision

• Precision: ±1 Hz for <100 Hz, ±1% for >100 Hz
• Digital sampling accuracy: <1%
• Overall accuracy: <5%

Display & Units

• LCD screen for frequency and tension (N) readout

Power Supply

• 4 × AAA batteries

Physical Dimensions

• Main unit size: approx. 140 × 72 × 34 mm

Operating Conditions

• Typical working environment: +10°C to +50°C

How It Works

The BTT2880S measures the vibration frequency of a belt when it is struck or in motion. After you enter belt details (mass, width, span), the tester calculates the belt tension using frequency data based on sonic principles. This method is non-contact and fast, making it suitable for regular maintenance and troubleshooting.

Applications

• Automotive belt tension checking and adjustment
• Industrial machinery belt maintenance
• Conveyor and HVAC belt tension diagnostics
• Workshop and field service belt tension measurement

Package Contents

• BTT2880S Sonic Belt Tension Tester main unit
• Detachable sensor probe
• Instruction manual
• Protective carrying case
