HT6510S-B Landtek
HT6510S-B Landtek
HT6510S-B Landtek

HT6510S-B Landtek

Rs.45,500/-
Brand:
Product Code: Sand Mould Surface Hardness Tester
Availability: In Stock
Viewed 4135 times

Product Description

HT6510S-B Landtek Sand Mould Surface Hardness Tester in Pakistan

The HT6510S-B Landtek Sand Mould Surface Hardness Tester is a professional instrument designed for measuring the hardness of fine and coarse sand mold surfaces. Built according to international standards, this model is the most commonly used in foundries and casting workshops across Pakistan for reliable and accurate quality control.

Features:


  • Complies with DIN 53505, ISO 868, ISO 7619, ASTM D2240, and JIS K7215 standards

  • Designed for sand mold surface hardness measurement (Types A, B, and C)

    • Type A: Fine sand mold/core in low–medium pressure molding

    • Type B (common model): Fine and coarse sand mold/core in low–medium pressure molding

    • Type C: Sand mold in high-pressure molding

  • Type B unit measured in g/mm², but commonly expressed as H(A/B/C)

  • Average value calculation function

  • Peak value hold and deposit function

  • Low battery alarm function

  • Automatic power-off function

  • USB data output for PC connectivity

  • Optional Bluetooth data output

Specifications:


ModelHT-6510S-AHT-6510S-BHT-6510S-C
Stroke2.50 mm2.50 mm2.50 mm
Load237 g980 g1500 g
Pressure Load90 g50 g180 g
Indenter ShapeSpherical R2.50Spherical R12.70Spherical R1.20
UnitHAHBHC
Display4-digit, 10 mm LCD4-digit, 10 mm LCD4-digit, 10 mm LCD
Display Range0 ~ 100 H(A/B/C)0 ~ 100 H(A/B/C)0 ~ 100 H(A/B/C)
Testing Range10 ~ 90 H(A/B/C)10 ~ 90 H(A/B/C)10 ~ 90 H(A/B/C)
Accuracy≤ ±1 H(A/B/C)≤ ±1 H(A/B/C)≤ ±1 H(A/B/C)
Resolution0.1 H(A/B/C)0.1 H(A/B/C)0.1 H(A/B/C)
Battery IndicatorLow Battery AlertLow Battery AlertLow Battery Alert
Auto Power OffYesYesYes
Operating Temp.0 ~ 40°C0 ~ 40°C0 ~ 40°C
Humidity Range< 80% RH< 80% RH< 80% RH
Power Supply2 x 1.5V AAA Batteries2 x 1.5V AAA Batteries2 x 1.5V AAA Batteries
Dimensions162 x 65 x 28 mm162 x 65 x 28 mm162 x 65 x 28 mm
Weight170 g170 g170 g

Package Includes:


  • Main Unit

  • Carrying Case (B04)

  • Operation Manual

Optional Accessories:


  • USB Data Cable with Software

  • Bluetooth Data Adapter with Software.
