HT6510S-A Landtek
HT6510S-A Landtek
HT6510S-A Landtek

HT6510S-A Landtek

Rs.43,500/-
Brand:
Product Code: Sand Mould Surface Hardness Tester
Availability: In Stock
Viewed 4117 times

Product Description

HT6510S-A Landtek Sand Mould Surface Hardness Tester in Pakistan

The HT6510S-A Landtek Sand Mould Surface Hardness Tester is a precision digital instrument designed to measure the hardness of sand mold and core surfaces. Built according to international standards, it is widely used in foundries, casting workshops, and quality control labs across Pakistan.

Features:

  • Meets DIN 53505, ISO 868, ISO 7619, ASTM D2240, and JIS K7215 standards

  • Sand mold surface hardness classified into Type A, Type B, and Type C

    • Type A: Fine sand mold/core in manual or mechanical low–medium pressure molding

    • Type B (most common): Fine and coarse sand mold/core in manual or mechanical low–medium pressure molding

    • Type C: Sand mold in high-pressure molding

  • Unit of measurement for Type B is g/mm² but usually expressed as H(A/B/C)

  • Average calculation function for accuracy

  • Peak value hold function

  • Low battery alarm

  • Auto power-off function

  • USB data output for PC connection

  • Optional Bluetooth data output for wireless transfer

Specifications:


ModelHT-6510S-AHT-6510S-BHT-6510S-C
Stroke2.50 mm2.50 mm2.50 mm
Load237 g980 g1500 g
Pressure Load90 g50 g180 g
Indenter ShapeSpherical R2.50Spherical R12.70Spherical R1.20
UnitHAHBHC
Display4-digit, 10 mm LCD4-digit, 10 mm LCD4-digit, 10 mm LCD
Display Range0 ~ 100 H(A/B/C)0 ~ 100 H(A/B/C)0 ~ 100 H(A/B/C)
Testing Range10 ~ 90 H(A/B/C)10 ~ 90 H(A/B/C)10 ~ 90 H(A/B/C)
Accuracy≤ ±1 H(A/B/C)≤ ±1 H(A/B/C)≤ ±1 H(A/B/C)
Resolution0.1 H(A/B/C)0.1 H(A/B/C)0.1 H(A/B/C)
Battery IndicatorLow Battery AlertLow Battery AlertLow Battery Alert
Auto Power OffYesYesYes
Operating Temp.0 ~ 40°C0 ~ 40°C0 ~ 40°C
Humidity Range< 80% RH< 80% RH< 80% RH
Power Supply2 x 1.5V AAA Batteries2 x 1.5V AAA Batteries2 x 1.5V AAA Batteries
Dimensions162 x 65 x 28 mm162 x 65 x 28 mm162 x 65 x 28 mm
Weight170 g170 g170 g

Package Includes:


  • Main Unit

  • Carrying Case (B04)

  • Operation Manual

Optional Accessories:


  • USB Data Cable with Software

  • Bluetooth Data Adapter with Software.
