HT-6510P Landtek Pencil Hardness Tester Price In Pakistan 2026
Buy Now HT-6510P Landtek Pencil Hardness Tester At Best Price In Pakistan 2026
The HT-6510P is a mechanical pencil hardness tester that measures coating hardness using the standard pencil scratch method. Simple to operate, accurate, and suitable for lab and field checks.
The HT-6510P Landtek Pencil Hardness Tester is a reliable mechanical instrument for evaluating the hardness of coating films using the pencil scratch test. The tester maintains a 45 degree measurement angle and uses two wheels plus a pencil core to provide three contact points for a consistent scratch track. The method follows relevant standards such as GB/T 6739 and ASTM D3363.
Operation is straightforward. Select the pencil hardness, position the tester at a 45 degree angle, and slide the instrument across the coating surface at roughly 1 mm per second. Compare the marks from different pencils to determine the coating hardness. The unit ships with three load options and a full accessory kit to allow repeatable, standardized testing.
This tester is ideal for coating manufacturers, quality control labs, paint shops, and R&D departments that need to verify finish durability and surface quality. For supply and after-sales support in Pakistan, contact LandtekInstruments.pk for pricing, bulk orders, and technical assistance.
Specifications:
-
Load Weight: 1000 g, 750 g, 500 g
-
Measurement Angle: 45°
-
Contact Points: Two wheels and one pencil core (three touch points)
-
Scratch Speed: Approximately 1 mm per second
-
Included: Pencil Hardness Tester, 1000 g weight, 750 g weight, 13 pencils (6B to 6H), eraser, knife, horizontal pad block, sandpaper
-
Standards: GB/T 6739-96, ASTM D3363-00, GB/T 1727-92.
coating hardness test, pencil scratch tester, ASTM D3363 pencil test, GB/T 6739 coating hardness, film hardness tester, pencil hardness method, surface hardness tester, paint hardness tester, 45 degree measurement angle, 1000g pencil tester, 750g hardness tester, 500g hardness test, QA coating test equipment, laboratory hardness tester, finish durability test, hardness pencil set 6B-6H, mechanical pencil tester, scratch speed 1 mm/s, pencil core hardness, horizontal pad block, Landtek instruments Pakistan, coating quality control Pakistan, paint film hardness, pencil hardness testing kit, buy pencil hardness tester Pakistan.
FAQ:
Q: What standards does the HT-6510P follow?
A: The tester uses the pencil hardness method and follows GB/T 6739 and ASTM D3363 standards.
Q: Which load weights are available?
A: 1000 g, 750 g, and 500 g are included in the standard configuration.
Q: Is this device suitable for lab and field use?
A: Yes. It is compact enough for basic field checks and robust enough for QA and R&D lab use.
