HGM-2000 Landtek Gloss Meter In Pakistan

The HGM-2000 Gloss Meter by Landtek is designed for precise surface gloss measurement across a wide variety of materials. It is suitable for industries that require accurate gloss testing for quality control and surface inspection.

Applications:

• Surface gloss measurement of floors, tiles, stones, and spray-painted surfaces

• Gloss testing for paint, ink, coating, wax films, and car body surfaces

• Gloss measurement for plastics, paper, and other non-metallic materials

• Suitable for industrial, laboratory, and quality assurance applications

• Capable of measuring gloss at three angles: 20°, 60°, and 85°

Features:

• Photometric Units: GU (Gloss Units)

• Measuring Range: 0 ~ 2000 GU

• Accuracy: ±1.5 GU (according to JJG 696-2002 reference standard)

• Resolution: 0.1 GU

• Repeatability: ±0.5 GU

• Error of Indication: Less than ±1.2 GU

• Projection Angles: 20°, 60°, 85°

• Fog Shadow Units (HU): Resolution ±0.1 HU, Repeatability ±0.2 HU, Reproducibility ±1.5 HU

• Measurement Area: 7 x 14 mm (elliptical)

• Memory Capacity: Stores up to 56 measurement groups

• Battery: Rechargeable 3.7V lithium battery

• Operating Temperature: 0°C to 40°C

• Relative Humidity: Less than 85%

• Weight: Approximately 310g (including battery)

• Size: 140 x 45 x 75 mm

Compliance with International Standards:

ASTM D523, ASTM D1455, ASTM C346, ASTM C584, ASTM D2457, ISO 2813, DIN 67530, EN ISO 7668, JIS Z8741, MFT 30064, GB 9754, GB/T 13891, GB 7706, GB 8807, and technical parameters compliant with JJG 696-2002.

Measurement Principle:

Gloss is measured as the percentage of reflected light from a surface. Haze is measured as the light scattering caused by surface microstructure imperfections. The device provides high accuracy gloss readings and haze evaluations for surface quality control. Lower haze values represent better surface clarity and smoothness.
