Product Description
GM026 Landtek Price In Pakistan 2026.
GM026 Landtek Gloss Meter 20° and 60° Dual Angle Measurement:
The GM026 Gloss Meter by Landtek is a compact and portable device designed for accurate measurement of surface gloss using 20° and 60° geometries. Its separate external probe allows for flexible and convenient operation in field or lab environments. Ideal for professionals involved in paint, printing, metal polishing, stone, tile, and surface finish inspections.
Key Features:
-
Dual measurement angles: 20° and 60°
-
Separate external probe for flexible use
-
Factory-calibrated with memory recall function
-
Stores up to 254 measurement groups
-
Compatible with international gloss standards
-
Data output via RS-232C interface
-
High accuracy and repeatability
Applications:
-
Floor surface maintenance and cleaning quality control
-
Tile and stone gloss measurement
-
Printed material gloss consistency
-
Paint and ink quality control
-
Polished metal inspection (chrome plating)
-
Waxing and surface protection testing
Technical Specifications:
| Parameter | Specification |
|---|---|
| Measuring Geometry | 20° and 60° |
| Measuring Range | 0.1 ~ 200 Gloss Units (GU) |
| Resolution | 0.1 GU |
| Accuracy | ±1.0 GU (against reference standard) |
| Repeatability | ±0.5 GU (0.0 to 99.9 GU) |
| Measuring Area | 7 × 14 mm ellipse |
| Data Memory | 254 measurement groups |
| Data Output | RS-232C serial interface |
| Main Unit Dimensions | 146 × 67 × 28 mm |
| Sensor Dimensions | 58 × 28 × 108 mm |
| Standard Compliance | ASTM D523, ASTM D2457, DIN 67530, JIS Z8741, GB 9754, and others |
| JJG Conformance | JJG 696-2002 |
Package Includes:
-
1 x GM026 Digital Gloss Meter
-
1 x External Probe
-
1 x Holder with Calibration Standard
-
1 x English Operation Manual
-
1 x Optic Cleaning Cloth
-
1 x Carrying Case
-
Standard Factory Packaging.
