GS100DA Landtek Digital Gauss Meter in Pakistan 2026

Buy GS100DA Landtek Gauss Meter in Pakistan – designed for high-precision measurement of AC, DC, remanent, and environmental magnetic fields. Compact, portable, and ideal for laboratory and industrial use.

The GS100DA Landtek Digital Gauss Meter is a professional-grade device used to measure various types of magnetic fields including:

• DC magnetic fields (static)

• AC magnetic fields (dynamic)

• Remanent magnetic fields

• Radiation magnetic fields

• Earth’s magnetic field

• And other environmental magnetic fields

Engineered with Hall Effect sensing technology, the GS100DA offers a wide measuring range, unit conversion between Gauss (Gs) and Millitesla (mT), peak hold functionality, and a user-friendly 4½-digit LCD display. This model is ideal for applications involving magnet inspection, sensor calibration, electromagnetic testing, and research work.

Applications:

• DC and AC magnetic field testing

• Remanent magnetism analysis

• Radiation field detection

• Magnetic sensor calibration

• Earth’s magnetic field monitoring

• Industrial and laboratory magnetic measurement

• Quality control of magnetized components

Key Features:

• Measures both AC and DC magnetic fields

• Wide range: 0–2000 mT

• Accurate results: ±2% (0–100 mT) and ±5% (above 100 mT)

• Peak hold function for capturing magnetic surges

• Unit conversion between mT and Gauss

• Detects magnetic polarity: N (North positive), S (South negative)

• Backlit 4½-digit LCD display

• Portable, lightweight, and easy to operate

• Powered by batteries or 5V external power source

Operating Principle:

The GS100DA uses the Hall Effect principle for magnetic sensing. Internally, it includes a low-drift amplifier and high-stability voltage supply, controlled by a microprocessor to ensure real-time, reliable readings on the LCD display.

Technical Specifications:

• Measuring Range:

  • DC ×1: 0.00 – 200.00 mT (Resolution: 0.01 mT)

  • DC ×10: 0.0 – 2000.0 mT (Resolution: 0.1 mT)

  • AC ×1: 0.00 – 200.00 mT (Resolution: 0.01 mT)

  • AC ×10: 0.0 – 2000.0 mT (Resolution: 0.1 mT)

• Frequency Range: 10 Hz – 200 Hz

• Accuracy:

  • 0–100 mT: ±2%

  • Above 100 mT: ±5%

• Display: 4½-digit LCD

• Polarity Detection: N for positive, S for negative

• Operating Temperature: 5°C to 40°C

• Humidity: 20% to 80% RH (non-condensing)

• Power Supply:

  • 4 × 1.5V AA batteries

  • Optional 5V external stabilized power source

• Dimensions: 140 × 73 × 30 mm

• Weight: 180 g

• Units: Switchable between Millitesla (mT) and Gauss (Gs)

Standard Accessories:

• GS100DA Main Unit

• Hall Sensor Probe

• Operating Manual.
