GS100D2 Landtek Digital Gauss Meter Price in Pakistan 2025.

Buy GS100D2 Landtek Gauss Meter in Pakistan – Accurate measurement of static and dynamic magnetic fields, including radiation, remanence, and earth’s magnetic field. Ideal for lab and industrial applications.

The GS100D2 Landtek Digital Gauss Meter is a precision magnetic field tester used for evaluating both DC (static) and AC (dynamic) magnetic fields. It's ideal for various applications such as magnetic material testing, remanent magnetism detection, electromagnetic field monitoring, and earth magnetic field evaluation.

Using Hall Effect sensing technology, this meter delivers reliable readings across a broad range. It supports mT/Gauss unit conversion, peak value hold, and has switchable range settings of 200mT and 2000mT. The clear 4½-digit LCD display provides excellent visibility, and the compact design makes it easy to use in the field or lab.

Applications:

• DC magnetic field analysis (static)

• AC magnetic field testing (dynamic, 10–200 Hz)

• Remanence and radiation field detection

• Environmental magnetic field measurement

• Magnetic equipment inspection

• Quality control of magnetized materials

• Laboratory research and calibration

Key Features:

• Measures both AC and DC magnetic fields

• Wide frequency range: 10 Hz to 200 Hz

• Dual measurement range: 0–200 mT and 0–2000 mT

• mT and Gauss unit conversion

• Peak hold function for transient magnetic detection

• Polarity detection (N for North, S for South)

• Clear 4½-digit LCD for real-time readings

• Compact, portable, and lightweight design

• Battery-powered for field use

• Suitable for magnetic inspection, R&D, and production environments

Operating Principle:

The GS100D2 is based on the Hall Effect principle, using a low drift amplifier and high-stability power supply controlled by a microcontroller. It processes and displays real-time magnetic field data accurately on a digital LCD interface.

Technical Specifications:

• Measuring Range:

  • DC ×1: 0.00 – 200.00 mT (Resolution: 0.01 mT)

  • DC ×10: 0.0 – 2000.0 mT (Resolution: 0.1 mT)

  • AC ×1: 0.00 – 200.00 mT (Resolution: 0.01 mT)

  • AC ×10: 0.0 – 2000.0 mT (Resolution: 0.1 mT)

• Frequency Range: 10 Hz – 200 Hz

• Accuracy: ±5% for DC and AC in uniform magnetic field

• Display: 4½-digit LCD

• Polarity Detection: N for positive, S for negative

• Operating Temperature: 5°C to 40°C

• Humidity: 20% – 80% RH (non-condensing)

• Power Supply: 4 × AAA (1.5V) batteries

• Dimensions: 140 × 73 × 30 mm

• Weight: 180 g

• Units: Switchable between mT (Millitesla) and Gs (Gauss)

Standard Accessories:

• GS100D2 Main Unit

• Hall Sensor Probe

• Operating Manual.
