The Landtek CM8856 Coating Thickness Gauge is a precision measuring device designed to check the thickness of coatings and platings on metal surfaces. Equipped with dual probe support (F and NF) and a separate probe design, it provides high flexibility for measuring in hard-to-reach or curved areas.

Suitable for measuring non-magnetic coatings on ferrous materials and non-conductive coatings on non-magnetic metals, the CM8856 is widely used in industrial quality control, automotive paint inspection, electroplating, and surface finishing processes.

Available across Pakistan including Karachi, Lahore, Islamabad, Sialkot, Faisalabad, and all major cities.

Key Features

• Supports F (Magnetic Induction) and NF (Eddy Current) probes

• Separate probe design for more flexibility in measurement

• Two modes: Single and Continuous measurement

• Stores up to 99 readings

• Auto calibration and substrate recognition

• USB/RS-232 data output, with optional Bluetooth connectivity

• Switchable between metric (µm) and imperial (mil) units

• Manual or auto shut down to save battery

• Lightweight and compact for industrial and on-site use

Working Principle

Technical Specifications

• Measurement Range: 0 to 1250 µm / 0 to 50 mil

• Resolution: 0.1 µm / 1 µm

• Accuracy: ±1 to 3% or ±2.5 µm

• Minimum Radius:
    F Probe: Convex 1.5 mm / Concave 25 mm
    NF Probe: Convex 3 mm / Concave 50 mm

• Minimum Measuring Area: 6 mm

• Minimum Sample Thickness: 0.3 mm

• Data Memory: 99 groups

• Power Supply: 2 × AAA (1.5V) batteries

• Operating Temperature: 0 to 40°C

• Operating Humidity: 10 to 90% RH

• Dimensions: 126 × 65 × 35 mm

• Weight (excluding battery): 81 g

Why Choose Landtek Instruments Pakistan

• Authorized distributor of Landtek instruments in Pakistan

• Fast shipping to all major cities

• Competitive and updated pricing

• After-sales support and warranty options

• Trusted by professionals in automotive, manufacturing, and quality control sectors.
