The Landtek CM8855 is a high-accuracy coating thickness gauge designed to measure the thickness of non-magnetic and non-conductive coatings. It supports both magnetic induction (F) and eddy current (N) measurement principles, making it suitable for a wide range of applications on both ferrous and non-ferrous metal surfaces.

This model is ideal for paint thickness inspections, galvanizing layer checks, and industrial surface treatment testing. Designed for use in quality control, automotive refinishing, marine, manufacturing, and other fields requiring precision coating measurement.

Available across Pakistan including Karachi, Lahore, Islamabad, Sialkot, and Faisalabad.

Key Features

• Dual measurement probes: Magnetic Induction (F) and Eddy Current (N)

• Stores up to 99 readings

• Single and Continuous measurement modes

• Automatically recognizes substrate material

• Auto calibration and measurement memory

• Switchable metric/imperial units

• USB/RS-232 data output with Bluetooth option

• Compact and lightweight for one-hand use

• Designed for curved, small, and large surface applications

Working Principle

Technical Specifications

• Measurement Range: 0 to 1250 µm / 0 to 50 mil

• Resolution: 0.1 µm / 1 µm

• Accuracy: ±1 to 3% or ±2.5 µm

• Minimum Radius: F: Convex 1.5 mm / Concave 25 mm, NF: Convex 3 mm / Concave 50 mm

• Minimum Measuring Area: 6 mm

• Minimum Sample Thickness: 0.3 mm

• Data Storage: 99 readings

• Power Supply: 2×AAA batteries

• Operating Temperature: 0 to 40°C

• Operating Humidity: 10 to 90% RH

• Dimensions: 126 × 65 × 35 mm

• Weight (without batteries): 81 g

Why Buy from Landtek Instruments Pakistan

• Official distributor of Landtek in Pakistan

• Updated prices with nationwide delivery

• Authentic product with local support

• Trusted by engineers, quality inspectors, and industries across Pakistan.
