The Landtek CM8829S is a dual-probe (F/N) coating thickness gauge designed to measure both non-magnetic coatings on magnetic materials and non-conductive coatings on non-magnetic metals. It supports Magnetic Induction and Eddy Current principles for a wide range of industrial and professional coating measurements.

This separate-type model offers enhanced flexibility by allowing probe changes for different surface shapes and materials. It supports single and continuous modes, Bluetooth connectivity (optional), and PC connectivity via USB/RS-232, making it ideal for use in automotive, manufacturing, painting, and QA environments.

Key Features

• Two measurement principles: Magnetic Induction (F) and Eddy Current (N)

• Supports Single and Continuous measurement modes

• Metric (µm) and Imperial (mil) units convertible

• Auto recognition of substrate type

• Memory retention of last calibration value

• Audible alerts in single mode (silent in continuous mode)

• Data transfer via USB/RS-232 interface

• Optional Bluetooth data output available

• Separate-type design allows probe switching for flexible measurement on different surfaces

• Manual and automatic power-off functions

Applications

F Type – Magnetic Induction (for magnetic base metals like steel):
Measures non-magnetic coatings such as:

• Galvanizing

• Lacquer and varnish

• Porcelain enamel

• Phosphate coatings

• Coated aluminum and copper tiles

• Some alloy and paper coatings

NF Type – Eddy Current (for non-magnetic base metals like aluminum or brass):
Measures non-conductive coatings such as:

• Anodizing

• Paint and varnish

• Enamel

• Plastic coatings

• Powder coatings

• Used on aluminum, brass, and non-magnetic stainless steel

Technical Specifications

Package Includes

• CM8829S Main Unit

• F/N Separate-Type Dual Probe

• Calibration Foils and Base

• USB Cable for PC connectivity

• Carrying Case

• User Manual
