The Landtek CM8828 is a reliable and efficient coating thickness gauge designed for measuring the thickness of non-magnetic coatings on magnetic substrates (F probe) and non-conductive coatings on non-magnetic metals (N probe).
It supports dual measurement principles—Magnetic Induction (F) and Eddy Current (N)—ensuring high accuracy and versatility for various industrial applications.
With USB/RS-232 data output, optional Bluetooth connectivity, and one-key operation, this device is ideal for professional quality control and inspection tasks.

Key Features

• Dual Measurement Methods: Magnetic Induction (F) and Eddy Current (N)

• Single and Continuous measurement modes

• Metric (µm) and Imperial (mil) units selectable

• Manual and automatic shutdown

• Automatic substrate recognition (ferrous/non-ferrous)

• Memory function for last calibration values

• Buzzer alert for single measurement (silent in continuous mode)

• USB/RS-232 interface for PC connection

• Optional Bluetooth data output

• One-key operation for quick and easy use

Applications

F Type (Magnetic Induction):
Used for non-magnetic coatings on magnetic materials like iron and steel. Examples: galvanizing, lacquer, enamel, phosphate layers.

NF Type (Eddy Current):
Used for non-conductive coatings on non-magnetic metals such as aluminum, brass, and stainless steel. Examples: paint, anodizing, varnish, powder coating, plastic films.

Measurement Examples

• Galvanized steel coating inspection

• Powder-coated aluminum profiles

• Automotive paint thickness testing

• Anodized aluminum thickness

• Enamel or plastic layers on metal parts

Technical Specifications

Package Includes

• CM8828 Main Unit

• Built-in F/N Dual Probe

• Calibration Base with Standard Foils (5 pieces)

• USB Cable for PC

• Carrying Case

• Operation Manual
