CM8823 Landtek Price In Pakistan 2026

Buy Now CM8823 Landtek At Best Price In Pakistan 2026.

The Landtek CM8823 is a high-precision digital coating thickness gauge designed to measure non-conductive coatings on non-magnetic metal surfaces. Using eddy current technology, it provides accurate measurements for coatings such as paint, enamel, varnish, powder, and anodized layers. Ideal for quality control in automotive, metal finishing, plating, and industrial coating industries.

Key Features

• Measurement Principle: Eddy Current (NF Type)

• Two measurement modes: Single and Continuous

• Supports both metric (µm) and imperial (mil) units

• Auto and manual power off options

• Automatic substrate recognition

• Stores calibration data automatically

• Audible alert for single measurement mode

• Low battery indicator

Applications

Used to measure non-conductive coating thickness on non-magnetic metals such as aluminum, brass, and non-magnetic stainless steel. Common in paint shops, powder coating plants, anodizing lines, and metal inspection labs.

Measurement Examples

• Paint on aluminum panels

• Powder coatings on brass surfaces

• Anodized aluminum

• Plastic coatings on stainless steel

Technical Specifications

• Measuring Range: 01000 µm / 040 mil

• Resolution: 0.1 µm / 1 µm

• Accuracy: ±(1~3%) or ±2.5 µm

• Minimum Radius (Workpiece): Convex 3 mm / Concave 50 mm

• Minimum Measuring Area: 6 mm

• Minimum Sample Thickness: 0.3 mm

• Unit Selection: Metric/Imperial convertible

• Operating Temperature: 0°C to 50°C

• Humidity: Less than 80% RH

• Power Supply: 4 × 1.5V AA batteries

• Dimensions: 161 x 69 x 32 mm

• Weight: 210g (excluding batteries)

Package Includes

• Main Unit (CM8823)

• NF Probe (Eddy Current)

• Calibration Base and Foils (5 pieces)

• Carrying Case

• Operation Manual

Why Choose Landtek Instruments Pakistan

• 100% original imported Landtek instruments

• Competitive pricing in Pakistan

• Delivery available in Karachi, Lahore, Islamabad, Sialkot, and all major cities

• After-sales support and guidance available locally.
