CM8821 Landtek Coating Thickness Gauge Price In Pakistan 2026

Buy Now CM8821 Landtek At Best Price In Pakistan 2026.

The CM8821 Landtek is a high-precision, portable coating thickness gauge used for measuring non-magnetic coatings (such as paint, enamel, lacquer, galvanizing, aluminum, copper, etc.) applied over magnetic substrates like iron and steel.

Using the F-type magnetic induction method, it provides fast and accurate measurements in various industries including automotive, construction, electroplating, and manufacturing. Its compact design and dual measurement modes make it ideal for both field use and laboratory testing.

Key Features

• Measures non-magnetic coatings on magnetic substrates (F-Type probe)

• Measurement principle: Magnetic Induction

• Two operation modes: Single and Continuous

• Continuous mode suitable for curved and small surfaces

• Selectable Metric/Imperial units

• Manual and automatic power-off options

• Memory for calibration values and auto substrate recognition

• Audible buzzer during measurement (silent in continuous mode)

• Low battery indicator

Technical Specifications

• Measurement Principle: F-type Magnetic Induction

• Range: 0 ~ 1000µm / 0 ~ 40mil

• Resolution: 0.1µm (below 100µm) / 1µm (above 100µm)

• Accuracy: ±1–3%n or ±2.5µm

• Minimum Radius of Workpiece:

  • Convex: 1.5mm

  • Concave: 25mm

• Minimum Measuring Area: 6mm

• Minimum Sample Thickness: 0.3mm

• Units: Metric / Imperial selectable

• Operating Temperature: 0 ~ 50°C

• Humidity: < 80% RH

• Power Supply: 4 × 1.5V AA (UM-3) batteries

• Dimensions: 161 × 69 × 32 mm

• Weight: 210g (excluding batteries)

Standard Accessories

• CM8821 Main Unit

• F-type Probe

• Calibration Base (F)

• 5-piece Calibration Foil Set

• Carrying Case (Model B04)

• User Manual

Why Buy from Landtek Instruments Pakistan

• 100% original Landtek product with warranty

• Fast delivery across Pakistan: Karachi, Lahore, Islamabad, Sialkot, and more

• Affordable and updated local pricing

• Technical support and customer service available
