CM8820 Landtek Coating Thickness Gauge – Magnetic Substrate Coating Meter in Pakistan

The CM8820 Landtek is a reliable digital coating thickness gauge used to measure the thickness of non-magnetic coatings (such as paint, plastic, porcelain enamel, copper, zinc, aluminum, chrome) on magnetic substrates (such as iron, nickel, and steel).

Designed to perform accurately in both laboratory and industrial field environments, this meter is ideal for manufacturing, quality control, and surface inspection applications.

Key Features

• Conforms to ISO2178 standard for magnetic induction measurement

• Measures non-magnetic coatings on ferromagnetic materials

• High accuracy and fast response using micro-computer LSI circuitry

• Durable ABS plastic housing designed for rugged use

• Large digital display for precise and clear readings

• Wide measurement range with high resolution

• Ergonomic design for comfortable handheld use

• Suitable for use in labs and harsh industrial environments

Technical Specifications

• Display: 4-digit LCD (10mm)

• Measuring Principle: Magnetic Induction (F Type)

• Measuring Range: 0 ~ 2000µm (0 ~ 80 mil)

• Resolution:

  • 0.1µm for 0–99.9µm

  • 1µm for ≥100µm

• Accuracy: ±5%n or ±5.0µm

• Operating Temperature: 0 ~ 40°C

• Humidity: < 80%

• Power Supply: 4 × 1.5V AA (UM-3) batteries

• Dimensions: 161 × 69 × 32 mm

• Weight: Approx. 260g (with batteries)

Standard Accessories

• Main unit

• F-type probe

• Calibration base (F)

• Calibration foils

• Carrying case

• User manual

Why Buy from Landtek Instruments Pakistan

• Original Landtek product with complete accessories

• Accurate and durable industrial-grade performance

• Fast nationwide delivery: Karachi, Lahore, Islamabad, Sialkot, and more

• Competitive pricing with warranty and support available
