CM1210B Landtek Coating Thickness Gauge In Pakistan

Buy Now CM1210B Landtek Coating Thickness Gauge At Best Price In Pakistan 2026

CM1210B Landtek Coating Thickness Gauge is a high-precision, non-destructive testing instrument designed to measure coating thickness on both ferrous and non-ferrous materials. It uses dual measurement technology including magnetic induction and eddy current, making it suitable for a wide range of industrial and inspection applications.

This model is widely used in automotive paint inspection, galvanizing, plating, manufacturing, and quality control processes. With its separate probe design and data storage capability, it provides flexibility and accurate results for professional use.

Key Features:

• Dual measurement technology (F and NF probes)
• Measures coatings on both ferrous and non-ferrous metals
• Wide measuring range up to 2000 µm
• High accuracy and stable readings
• Data storage up to 99 groups
• Separate probe for flexible operation
• Automatic substrate recognition
• Continuous and single measurement modes
• Metric and imperial unit selection
• Optional USB, RS-232, and Bluetooth connectivity

These features are confirmed from official product listings and datasheets

Technical Specifications:

Measurement Principle:

• Magnetic Induction (F Type)
• Eddy Current (NF Type)

Measuring Range:

• 0 to 2000 µm (0 to 80 mil)

Resolution:

• 0.1 µm (low range)
• 1 µm (high range)

Accuracy:

• ±1% to ±3% or ±2.5 µm

Measurement Capability:

• F Probe: Non-magnetic coating on ferrous metals
• NF Probe: Non-conductive coating on non-ferrous metals

Minimum Requirements:

• Minimum Measuring Area: 6 mm
• Minimum Substrate Thickness: 0.3 mm

Surface Radius:

• F Type: Convex 1.5 mm / Concave 25 mm
• NF Type: Convex 3 mm / Concave 50 mm

Data Storage:

• 99 groups of readings

Display and Functions:

• Digital LCD display
• Auto calibration memory
• Audible indication (buzzer)
• Auto substrate detection

Power Supply:

• 4 × AAA batteries

Operating Conditions:

• Temperature: 0°C to 40°C
• Humidity: 10% to 90% RH

Physical Specifications:

• Dimensions: 140 × 72 × 34 mm
• Weight: Approx. 215 g

Applications:

• Automotive paint thickness inspection
• Galvanized coating measurement
• Industrial coating quality control
• Metal surface finishing inspection
• Manufacturing and plating industries

Package Includes:

• Main unit
• F and NF probes
• Calibration bases
• Calibration foils (set)
• Carrying case
• User manual
