Product Description

CM1210A Landtek Coating Thickness Gauge Price In Pakistan 2026


Buy Now CM1210A Landtek Coating Thickness Gauge At Best Price In Pakistan 2026.


The CM1210A Landtek Coating Thickness Gauge is a high-precision dual-probe device designed for non-destructive testing of coatings on various metal substrates. It measures non-magnetic coatings on magnetic materials (F Type) and non-conductive coatings on non-magnetic metals (NF Type). It is suitable for quality control, inspection, and industrial surface evaluation.

Key Features

  • Dual measurement principles: Magnetic Induction (F Type) and Eddy Current (NF Type)

  • Wide measuring range: 0 to 2000 µm / 0 to 80 mil

  • High resolution: 0.1 µm / 1 µm

  • Accuracy: ±1–3% or ±2.5 µm

  • Single and continuous measurement modes

  • Automatic calibration memory and substrate recognition

  • Metric and imperial unit selection

  • Optional data output via USB, RS-232, or Bluetooth

  • Separate probe design for flexible use

  • Buzzer feedback during measurement (optional)

Measurement Applications

Probe TypePrincipleTypical Applications
F TypeMagnetic InductionGalvanized coatings, lacquer, enamel, phosphide, copper and aluminum tiles
NF TypeEddy CurrentAnodizing, paint, varnish, powder coatings on aluminum, brass, stainless steel

Technical Specifications

SpecificationDetails
Range0 to 2000 µm / 0 to 80 mil
Resolution0.1 µm / 1 µm
Accuracy±(1–3%) or ±2.5 µm
Minimum Radius (F)Convex: 1.5 mm / Concave: 25 mm
Minimum Radius (NF)Convex: 3 mm / Concave: 50 mm
Minimum Measuring Area6 mm
Minimum Sample Thickness0.3 mm
UnitsMetric / Imperial
Operating Temperature0°C to 40°C
Humidity Range10% to 90% RH
Power Supply4 × AAA batteries
Dimensions140 × 72 × 34 mm
Weight215 g (excluding batteries)

Package Contents

  • Main unit

  • F Type probe

  • NF Type probe

  • Calibration bases for F and NF

  • Calibration foils (1 set, 2 pieces)

  • Carrying case

  • Operation manual
