CM1210-200N Landtek Coating Thickness Gauge Price In Pakistan 2025.
The CM1210-200N Landtek Coating Thickness Gauge is a non-destructive testing instrument that uses eddy current technology (NF Type) to measure non-conductive coatings on non-magnetic metal substrates such as aluminum, brass, and non-magnetic stainless steel.
Designed for quality control, surface treatment analysis, and paint layer inspection, this thickness meter is ideal for use in industries across Pakistan including automotive, HVAC, plating, metal processing, and coating inspection sectors.
Key Features
-
NF Type Probe: Uses eddy current to measure non-conductive coatings on non-magnetic metals
-
Measurement Range: 0 ~ 200 µm / 0 ~ 8 mil
-
Resolution: 0.1 µm / 1 µm
-
High Accuracy: ±(1 µm + 3% of reading)
-
Automatic recognition of substrate material
-
Memory for last calibration value
-
Single & Continuous Modes (ideal for small/curved parts)
-
Metric/Imperial unit toggle
-
USB or optional Bluetooth output for PC integration
-
Buzzing feedback during measurements (silent in continuous mode)
Application Examples
-
Paint coating on aluminum parts
-
Plastic coatings on non-magnetic metals
-
Powder-coated HVAC components
-
Anodized aluminum surface thickness checks
-
Varnish or enamel layers on brass or copper
Technical Specifications
| Feature | Specification |
|---|
| Principle | Eddy Current (NF Type) |
| Measurement Range | 0 to 200 µm / 0 to 8 mil |
| Resolution | 0.1 µm / 1 µm |
| Accuracy | ±(1 µm + 3%H) |
| Min Radius (Convex/Concave) | 2 mm / 4 mm |
| Min Sample Thickness | 0.1 mm |
| Units | Metric / Imperial |
| Operating Temp | 0 ~ 40°C |
| Humidity Range | 10% ~ 90% RH |
| Power Supply | 4 × AAA Batteries (1.5V UM-4) |
| Dimensions | 140 × 72 × 34 mm |
| Weight | 215 g (excluding batteries) |
What's in the Box
-
CM1210-200N Main Unit
-
NF-Type Probe (Eddy Current)
-
Calibration Base (NF Type)
-
Calibration Foils (1 set, 2 pieces)
-
Carrying Case (Model B04)
-
User Manual
Optional Accessories
