HM934-1+ Landtek Price In Pakistan

The HM934-1+ Landtek Barcol Impressor is a highly accurate, portable digital hardness tester designed for testing aluminum and aluminum alloys. It is suitable for a wide range of applications in manufacturing, quality control, and metal processing industries. With features like balance positioning, non-disassembly calibration, digital display, and Bluetooth data output, this upgraded version of the HM934-1 offers more functionality for advanced users.

Features:

• Digital indentation hardness tester with balance positioning and calibration without disassembly

• High stability and measurement accuracy

• Compact and portable for easy one-handed use in any position

• Wide test range: suitable for pure aluminum to hard aluminum alloys (equivalent to 25–135 HBW)

• Requires only single-side testing—no support required on the reverse side

• Measures Barcol Hardness and supports conversion to Brinell (HB), Vickers (HV), Webster (HW), and Rockwell (HRB, HRE, HRF, HRH)

• Maximum hold function stores the peak hardness value

• Average value function calculates the mean of up to 29 data sets

• Optional Bluetooth data output for easy data transmission to PC

Technical Specifications:

• Measurement Range: 0 ~ 100 HBa (equivalent to 25 ~ 135 HBW)

• Resolution: 0.1 HBa

• Indication Error:

  • 81 ~ 88 HBa: ±1 HBa

  • 42 ~ 48 HBa: ±2 HBa

• Repeatability Error:

  • 81 ~ 88 HBa: ±1.5 HBa

  • 42 ~ 48 HBa: ±2.5 HBa

• Hardness Conversions: Brinell (HB), Vickers (HV), Webster (HW), Rockwell (HRB/HRE/HRF/HRH)

• Functions: Maximum Hold, Average Calculation (up to 29 sets)

• Operating Conditions: Temperature 0°C ~ 50°C, Humidity <80% RH

• Power Supply: 2 x 1.5V AAA (UM-4) batteries

• Dimensions: 170 x 63 x 82 mm

• Weight: 390g (excluding batteries)

Included Accessories:

• Main Unit

• 2 Indentation Pins

• 2 Standard Test Blocks

• Screwdriver

• Spanner

• Carrying Case

• Operation Manual

• Optional: Bluetooth Data Adapter with Software.
