HM934-1 Landtek Barcol Impressor In Pakistan

The HM934-1 Barcol Impressor by Landtek is a digital indentation hardness tester specially designed for accurate testing of aluminum and aluminum alloys. Engineered for convenience, precision, and portability, it features a digital display, single-hand operation, and a wide test range. This device allows fast, stable hardness measurements without needing to support the reverse side of the sample, making it ideal for use in production environments, workshops, and on-site quality control.

Features:

• Digital Barcol hardness tester with digital display and non-disassembly calibration

• Stable performance with high detection accuracy

• Compact and portable, ideal for one-handed operation in any orientation

• Wide hardness range, suitable for testing soft pure aluminum and hard aluminum alloys

• No backside support needed for testing

• Measures Barcol Hardness directly; other values like Brinell (HB), Vickers (HV), Webster (HW), Rockwell (HRB/HRE/HRF/HRH) can be derived using conversion curves

• Maximum hold function captures the peak reading during measurement

• Optional Bluetooth data output available for easy connectivity

Technical Specifications:

• Measurement Range: 0 ~ 100 HBa (equivalent to 25 ~ 135 HBW)

• Resolution: 0.1 HBa

• Indication Error:

  • 81 ~ 88 HBa: ±1 HBa

  • 42 ~ 48 HBa: ±2 HBa

• Repeatability Error:

  • 81 ~ 88 HBa: ±1.5 HBa

  • 42 ~ 48 HBa: ±2.5 HBa

• Maximum Hold: Supported

• Average Calculation: Not supported

• Operating Temperature: 0°C ~ 50°C

• Humidity: < 80% RH

• Power Supply: 2 x 1.5V AAA (UM-4) batteries

• Dimensions: 170 x 63 x 82 mm

• Weight: 390g (excluding batteries)

Included Accessories:

• Main Unit

• 2 Indentation Pins

• 2 Standard Blocks

• Screwdriver

• Spanner

• Carrying Case

• Operation Manual

• Optional: Bluetooth Data Adapter with Software.
